The PHOTONTEK Digital Lighting Controller is a full-control LED fixture master panel, that allows you to harness the full power of our entire LED lighting range.

Using the newest tech available, this smart-feature accessory will quickly become your best grow mate as it constantly monitors and helps to maintain your environmental temperatures, lighting schedules & intensity automation.

Smart, but still incredibly user friendly, this unit is a twin channel controller. Giving growers the ability to control individual ‘zones’, capable of operating up to 50 LED fixtures each!

Using an analog 0-10V signal, each channel (Zone) can either control the same-powered LED drivers; Zone A can control the same-powered drivers as Zone B OR Zone B can be set to control different powered LED drivers. Eg: Zone A can be set to control 465W LED fixtures and Zone B set to control 600W, with the same accuracy and safety protections across your entire set-up.

Note: For discreet shipping, please add a customer note to your order stating so.

Features

Control panel for up to 100 LED drivers
Compatible only with PhotonTek Controllable LED drivers & fixtures; SQ200, SQ300, 465W, 600W & 1000W
Light Timing
24hr Light scheduling and switching, including the ability to simulate sunrise and sunset periods, for perfectly imitating natural environments.
Temperature-control dimming & switching for safety control
Automate light intensity and therefore your PPFD totals for specific times.
Accurate dimming control of increments of 1%

Additional info

PhotonTek Catalog

Specs

Product Code: PTEKM0017

Power: Adaptor 100 – 277V AC 50/60Hz – DC 5V/2A

Match LED Driver: 465W, 600W, 1000W

Power Dimming Range: 0%, 10% – 100%

Power Regulation Accuracy: 1%

Temperature-controlled Safety Dimming range: 0ºC-40ºC

Temperature-controlled Safety Switching range: 10ºC-50ºC

Sunrise and Sunset Duration: 0-30 min

Dimensions: 125 x 80 x 25mm

What's in the box

1 x PHOTONTEK Control Panel Plus
1 x PhotonTek Digital Controller
1 x Power adaptor and cable
2 x Temperature sensor 5m cable
2 x LED control link cable
